Hex Bolts

Hex Bolts

Hex bolts have hexagonal heads and machine threads for use with a nut or in a tapped hole. Also known as hex cap screws or machine bolts.


SpecificationAs per ISO, ASTM, BS, DIN standards, special head bolt as per customer drawing.

Material Grade :Gr 4.6, 5.8, 8.8, 10.9, 12.9, B7, B7M, 304, 316/L, 310, 321, Monel, incolloy, Duplex and Super Duplex stainless steel etc.

Size Range : M6 to M64 (1 /4” to 2-1/2”) in length of up to 1.7 meter long.

Finish : Self colour, Black, Zinc plated, Hot Dip Galvanized, PTFE etc as per various international standards.

Technical Information
